0.25M~125.0M 請?jiān)诖颂顚懟蜻x擇
(*填寫時需要加K/M/G)
請?jiān)诖诉x擇
| 溫度頻差VS溫度范圍 | ±20ppm | ±25ppm | ±30ppm | ±50ppm | ±100ppm |
|---|---|---|---|---|---|
| -20~70℃ | |||||
| -40~85℃ | |||||
| -40~105℃ | |||||
| -55~125℃ |
Specs
所選參數Item
KS25Output Logic
CMOSNominal Frequency
左邊填寫Operating Voltage
左邊填寫Frequency Tolerance
±30ppmFrequency Stability
左邊選擇Operating Temperature
左邊選擇Output Level
--Current Consumption
--Jitter
NADuty Cycle
45~55% (f≤40MHz) 40~60% (f＞40MHz)Rise/Fall Time
5ns maxStart-up Time
5ms maxSpecial Requirement
左邊選擇Specs
所選參數Item
KS25Output Logic
CMOSNominal Frequency
0.25M~125.0MOperating Voltage
1.2V~5.0VFrequency Tolerance
±30ppmFrequency Stability
±10ppm~±100ppmOperating Temperature
-55℃ min;+125℃ maxOutput Level
--Current Consumption
--Jitter
NADuty Cycle
45~55% (f≤40MHz) 40~60% (f＞40MHz)Rise/Fall Time
5ns maxStart-up Time
5ms maxSpecial Requirement
有/無
